NEW GENERATION

Per request from your side.
Quality and reliability remain while the vehicle concept has been overhauled in close collaboration with international customers. Completely new: the intuitive control, which was developed based on the latest ergonomic insights, the most powerful engine in its class, the eco-friendly exhaust gas technology, the cockpit, the seat and a wealth of other practical innovations.

Pioneering is the completely new kind of operating concept, which includes the operator’s entire workstation. The centrepiece of the new control panel, which

is fully integrated in the armrest, is an innovatively designed 4-axis joystick, enabling the driver to control the blade intuitively with full freedom of movement with one hand.

Rejoice in the new addition to the PistenBully family.

SHOWROOM

The best at a glance

MOST POWERFUL ENGINE

IN ITS CLASS

Economical and efficient: With twenty percent more thrust, the PistenBully 100 is now more agile and more powerful. And that with less fuel consumption.

ECO-FRIENDLY

EXHAUST GAS TECHNOLOGY

Low-emission engine: The PistenBully 100 features a diesel particulate filter. Since the beginning of this year, it is being offered as standard, thereby fulfilling EU Stage V.

UNRIVALLED

UNPOLLUTED

The PistenBully 100 is currently the only vehicle in its class that is available from the manufacturer with a diesel particle filter. This reduces pollutant emissions significantly.

NEW ALL-WAY-BLADE

HIGH-VOLUME AND SENSITIVE

A taller snow guard and extended working widths for greater snow volumes. Synchronized control of side wings with reinforced bearings. Tiller and blade can be operated simultaneously using the joystick.

LONGER, BETTER, DEEPER

NEW QUICK-CHANGE SYSTEM

Longer quick-change system (QCS) pushframe for improved visibility of the All-Way-Blade and a new lift cylinder for greater range of movement from the quick-change system.

ALSO USABLE

AS PARK VERSION

With a special quick-change system the PistenBully 100 is suitable for use in parks. The back blading feature facilitates perfect grooming of feature finishes.

MORE BITE THAN EVER

DIFFERENT WORKING WIDTHS

More efficient passes due to a broader tiller shaft and larger working width. More teeth for improved snow surface. Tiller depth and contact pressure of the tiller and track setters can be adjusted autonomously.

WIDE RANGE

TRACK SETTERS FOR EACH USE

Precise trail grooming and improved terrain conformance thanks to deeper track setters. When not in use the track tiller (VarioTrackDesigner) can be simply removed without tools.

CHASSIS AND TRACKS

MORE STABLE AND LOWER

Best gradability thanks to 4 running axles, higher payloads and improved service accessibility distinguish the chassis of the PistenBully 100. The automatic track tensioning reduces the wear and tear.

VIDEO

COCKPIT

Ergonomic and individually adjustable.

PATENTED

ITERMINAL

Patented iTerminal with optimized user guide thanks to color labelling of the active areas of the vehicle.

JOYSTICK

SIMPLY INTUITIVE

With proportional control for intuitive working: The newly developed double-jointed
joystick moves freely in all directions.

ARMREST

FATIGUE-FREE HANDLING

Armrest with convenient and individually programmable customer buttons.

100 ENGINE

Most powerful engine in its class, economical and efficient.

TECHNICAL DATA

Type Cummins QSB 6,7
Cylinders 6
Displacement 6.7 l / 6,700 cc
Power output (ECE) 186 kW / 253 PS / 249 hp
max. torque 990 Nm at 1.500 rpm
Fuel tank capacity 155 l (41 gal)
Fuel consumption from 8.5 l/h (2.24 gal/h) 1,500
Tank capacity AdBlue 19 l (5 gal)
Exhaust emission standard EU Stage V

Power and high torque coupled with excellent fuel economy
The powerful, 6-cylinder in-line diesel engine with common rail fuel injection offers low fuel consumption along with low noise and exhaust emissions. It complies with the Tier 4 final standard thanks to an exhaust gas after-treatment system.

READY FOR SNOWSAT

The vehicle comes with all interfaces for SNOWsat fully integrated as standard. The optional display screen opens up the world of economical and eco-friendly snow and fleet management for you.

With SNOWsat you get the maximum from your fleet. The fleet management improves coordination and control of all vehicles and optimizes workflows. At the

same time, the detailed analyses help you to save fuel and reduce operating times. It increases safety for snow grooming and supports needs-oriented production of machinemade snow.

Additionally: SNOWsat can also be retrofitted in all of the other vehicles in your fleet – regardless the brand.
